Vehicle Restraint
Evaluate restraint compatibility with the vehicle rear impact guard and operating procedure. Final selection depends on the documented site conditions and the supplying manufacturer’s configuration.
Add to bay brief
Where to consider this arrangement
Evaluate restraint compatibility with the vehicle rear impact guard and operating procedure.
- Confirm vehicle rear geometry.
- Confirm mounting positions and foundations.
- Confirm signals and control interfaces.
When to review alternatives
Do not select this arrangement if the required working space, mounting conditions or operating envelope cannot be demonstrated. Existing equipment and civil works must be measured before a replacement is proposed.
Dock BumpersDock Traffic Lights & Loading LightsWheel Guides & Wheel ChocksHow is vehicle compatibility reviewed?
Provide rear-vehicle photographs and the relevant impact-guard geometry. Ask the supplier to confirm compatibility with the proposed restraint, mounting and signal sequence; appearance alone does not establish compatibility.
Vehicle rear impact-guard details
Mounting and foundation layout
Driver and operator signal sequence
Specifications and configuration
| Item | Project record |
|---|---|
| Product reference | JD-2009 |
| Vehicle rear geometry | Confirmed per project |
| Mounting positions and foundations | Confirmed per project |
| Signals and control interfaces | Confirmed per project |
| Dimensioned drawing | Available on request — confirmed per project |
Source: JBL Dock Catalogue V1.2 (review edition) and website planning framework. Content reviewed for this draft: 17 October 2026. Technical values and configuration require project confirmation.
The catalogue reference table below distinguishes review values from unresolved entries. These are not approved order specifications. No certification or universal compatibility is claimed.
Catalogue configuration reference
Review data—not an approved order specification. The entries below are transcribed from Catalogue V1.2 and remain subject to technical confirmation.
JD-2009 · JD-2009 family · Catalogue pages 16–17
| Parameter | Review catalogue entry | What to confirm |
|---|---|---|
| Engagement | Hook arrangement at vehicle rear impact guard | Provide actual vehicle geometry. |
| Controls | Restraint status and interlocks require definition | Agree signalling and equipment sequence. |
| Mounting | Foundation and anchor requirements need project review | Obtain the selected product installation drawing. |
Open technical items: Operating description and response-time claim need reconciliation. Certification and performance figures are withheld pending supporting evidence.
What should be checked?
Agree the inspection scope with the supplying manufacturer before order. Relevant checks include dimensions against the approved drawing, component identity, mounting details, visible condition, applicable functional checks, marking and packing.
Inspection records to agreeWhat configuration is required?
Describe the operating sequence and site constraints. Confirm materials, finish, electrical requirements and control interfaces where applicable. Options shown in reference illustrations are not automatically included in the order.
Know what your quotation includes
Compare the same equipment and installation scope. Ask for an itemised offer showing the selected configuration, included items and exclusions.
No universal standard package is confirmed in this review. Agree the following scope before comparing prices.
| Scope to identify | Written confirmation to request |
|---|---|
| Restraint, alignment, impact protection or signalling function | Exact model, construction and drawing revision. |
| Mounting geometry, foundations and cables where relevant | Included equipment, separately priced options and excluded site work. |
| Vehicle compatibility and operating sequence | Interfaces, responsibilities and required documentation. |
A simpler way to request a comparable quotation
Start with a short description or photo. Add the following when available; mark anything unknown so it can be resolved together.
| Share with your enquiry | What this helps clarify |
|---|---|
| Vehicle rear impact-guard details | Equipment fit and selection |
| Mounting and foundation layout | Installation and interface requirements |
| Driver and operator signal sequence | The configuration to review |
| Quantity, location and preferred schedule | Supply and delivery planning; dates require confirmation. |
| Existing or new installation | Existing structures and equipment to measure and review. |
| Required documents and inspection records | Acceptance evidence and responsibilities before order. |
Keep the product information together
Catalogue V1.2 · Pages 16–17 · JD-2009 family. Review edition: final configuration and technical details require confirmation.
